China Extruded Solid Polyacetal Acetal POM Sheet Manufacturers, Factory

Product Detail

POM—a revolutionary engineering thermoplastic material that is sweeping the industry! POM is the material of choice for fabrication due to its high crystallinity and near-metallic mechanical properties.

POM, also known as polyoxymethylene, is a crystalline and highly crystalline thermoplastic engineering plastic material. Its mechanical properties make it ideal for the production of components for mechanical equipment. Furthermore, it can withstand high temperatures up to 100°C, making it a versatile material for a wide range of applications.

One of the most exciting advancements in the POM industry is the introduction of colored POM sheets. These sheets can be used to manufacture components in a variety of colors and shapes, making them ideal for automotive, electronics, medical devices, packaging services, food machinery and many other sectors. This versatility and flexibility of use has made POM the material of choice for many manufacturers.

The benefits of POM don't stop there. Consumers can use two types of POMs - POM-C and POM-H. POM-C, also known as polyoxymethylene copolymer, has become the most popular and widely used material on the market. This material is ideal for applications requiring high precision and tight tolerances. On the other hand, POM-H is an acetal homopolymer known for its high mechanical strength and heat resistance. This type of POM is used in applications requiring greater strength and durability.

From making gears, bearings and pump casings to making other mechanical components - POM has become the material of choice for many industries. Its properties, versatility, and heat resistance make it one of the most sought-after materials for future engineering and manufacturing.

In conclusion, if you are looking for a durable, versatile and highly heat resistant material, then POM is the perfect solution for your needs. Its unique properties and versatility make it an ideal material for the manufacture of various industrial machine components. With its high performance and low production cost, POM is a one-of-a-kind material that is sure to revolutionize manufacturing in the coming years.

Product Specification

Colored POM Board Specification Data Sheet
	Description	Item No.	Thickness (mm)	Width & Length (mm)	Density (g/cm³)
	Colored POM Board	ZPOM-T-C	10~100	600x1200 / 1000x2000	1.41
	Tolerance (mm)	Weight (kg/pc)	Color	Material	Additive
	+0.2~+2.0	/	Any Color	LOYOCON MC90	/
	Volume Abrasion	Friction Factor	Tensile Strength	Elongation at Break	Bending Strength
	0.0012 cm³	0.43	64 MPa	23%	94 MPa
	Flexural Modulus	Charpy Impact Strength	Heat Distortion Temperature	Rockwell Hardness	Water Absorption
	2529 MPa	9.9 kJ/m²	118 °C	M78	0.22%

Product Size

Item Name	Thickness (mm)	Size (mm)	Thickness Tolerance (mm)	Est. Net Weight (KGS)
Delrin POM Plate	1	1000x2000	(+0.10) 1.00-1.10	3.06
	2	1000x2000	(+0.10) 2.00-2.10	6.12
	3	1000x2000	(+0.10) 3.00-3.10	9.18
	4	1000x2000	(+0.20) 4.00-4.20	12.24
	5	1000x2000	(+0.25) 5.00-5.25	15.3
	6	1000x2000	(+0.30) 6.00-6.30	18.36
	8	1000x2000	(+0.30) 8.00-8.30	26.29
	10	1000x2000	(+0.50) 10.00-10.5	30.50
	12	1000x2000	(+1.20) 12.00-13.20	38.64
	15	1000x2000	(+1.20) 15.00-16.20	46.46
	20	1000x2000	(+1.50) 20.00-21.50	59.76
	25	1000x2000	(+1.50) 25.00-26.50	72.50
	30	1000x2000	(+1.60) 30.00-31.60	89.50
	35	1000x2000	(+1.80) 35.00-36.80	105.00
	40	1000x2000	(+2.00) 40.00-42.00	118.83
	45	1000x2000	(+2.00) 45.00-47.00	135.00
	50	1000x2000	(+2.00) 50.00-52.00	149.13
	60	1000x2000	(+2.50) 60.00-62.50	207.00
	70	1000x2000	(+2.50) 70.00-72.50	232.30
	80	1000x2000	(+2.50) 80.00-82.50	232.30
	90	1000x2000	(+3.00) 90.00-93.00	268.00
	100	1000x2000	(+3.50) 100.00-103.5	299.00
	110	610x1220	(+4.00) 110.00-114.00	126.8861
	120	610x1220	(+4.00) 120.00-124.00	138.4212
	130	610x1220	(+4.00) 130.00-134.00	149.9563
	140	610x1220	(+4.00) 140.00-144.00	161.4914
	150	610x1220	(+4.00) 150.00-154.00	173.0265
	160	610x1220	(+4.00) 160.00-164.00	184.5616
	180	610x1220	(+4.00) 180.00-184.00	207.6318
	200	610x1220	(+4.00) 200.00-205.00	230.702

Product Process

Product Feature

✓ Superior mechanical property
✓ Dimensional stability and low water absorption
✓ Chemical resistance, medical resistance
✓ Creep resistance, fatigue resistance
✓ Abrasion resistance, low coefficient of friction

Product Certificate

Product Packing

Product Application

Frequently Asked Questions (FAQ)

Q1: What is POM and why is it preferred for mechanical applications?

POM (Polyoxymethylene) is a highly crystalline thermoplastic engineering plastic. Due to its high crystallinity and near-metallic mechanical properties, it offers superior strength, stiffness, outstanding creep resistance, and low friction, making it ideal for precision engineering parts.

Q2: What is the main difference between POM-C and POM-H?

POM-C is a polyoxymethylene copolymer that is highly popular for precision applications requiring tight tolerances. POM-H is an acetal homopolymer designed for applications demanding higher mechanical strength, hardness, and elevated heat resistance.

Q3: What are the key features and physical properties of POM boards?

POM boards boast excellent dimensional stability, low water absorption (typically 0.22%), chemical and medical resistance, and high tensile strength (approx. 64 MPa). They operate reliably in temperatures up to 100°C.

Q4: What sizes and thickness options are available for Delrin POM plates?

Delrin POM plates come in thicknesses ranging from 1mm up to 200mm. Standard dimensions include 1000x2000mm for thinner configurations and 610x1220mm for thicker blocks, with precise tolerances applied to ensure consistency.

Q5: Which industries commonly use colored POM sheets and components?

Colored POM sheets are widely applied in the automotive, electronics, medical devices, food machinery, packaging, and general manufacturing industries for creating gears, bearings, pump casings, and other critical machine components.
